NEW MAXUS Backhoe Loader Warranty up to 10 YEARS | НОВА Екскаватор-навантажувач MAXUS Гарантія до 10 РОКІВ — crédit-bail
Publié: 5mois 13jour(s)
Publié: 5mois 13jour(s)
Poland, Gdańsk, ul. Kontenerowa 21, Magazyn Przeładunkowy.Machines, equipment, and vehicles qualify for all assistance programs.
TESTS on MAXuSA
Each of our tractors or machines can be tested within 14 days from the date of delivery. This time will allow you to check the equipment in your working conditions.
MAXuSA SERVICES
100+ cooperating stationary service centers and workshops
100+ cooperating mobile service centers
100+ cooperating tow trucks
Become our Customer - MAXUS brand AMBASSADOR
You may ask how this works? Initially, you will receive the machine at half the price — the rest you will pay by promoting the MAXUS brand.
Together we can achieve more.
Join us today — we are waiting for you!
Short on cash?
No problem.
We offer bank and non-bank financing for our sold machines, equipment, and vehicles.
We can offer:
operational leasing — bank and non-bank
financial leasing
leasing loan
investment loan or for any other purpose, including EU-supported credit
factoring loan
non-bank loan
Leasing for companies and farmers from day one of operation.
Also
Statement loan
Without checking BIK, KRD databases
Own contribution required.
Overall Dimensions
Length (with bucket on the ground): 6450 ± 80 mm
Overall width (with stabilizer): 2650 ± 20 mm
Bucket width: 2620 mm
Height (to the top of the cabin): 3120 ± 10 mm
Height (to the top of the digging arm): 3940 ± 20 mm
Wheelbase: 2335 ± 10 mm
Rear wheel tread: 2139 ± 10 mm
Main Loader Specifications
Rated load: 2500 KG
Working weight: 9120 kg
Rated bucket capacity: 1.2 m³
Max. unloading clearance: 3050 ± 50 mm
Dump reach: 870 ± 20 mm
Reach beyond bucket: 5750 ± 50 mm
Main Excavating Specifications
Rated digging bucket capacity: 0.3 m³
Max. digging depth: 3820 ± 20 mm
Max. digging radius: 5345 ± 20 mm
Max. unloading height: 3740 ± 20 mm
Max. digging force: kgf
Max. digging height: 5470 ± 20 mm
Lifting force at max. digging radius: 1220 kg
Max. digging depth (telescope arm): 4970 ± 20 mm
Max. loading height (telescope arm): 4983 ± 20 mm
Max. digging height (telescope arm): 6680 ± 20 mm
Diesel Engine
Model: YC4A105Z-T20
Manufacturer: Yuchai
Rated power: 75 (kW)
Engine capacity: 4.8 (L)
Rated speed: 2200 (r/min)
Max. torque: 400 (NM)
Transmission System
Torque converter model: 315
Cooling type: Oil pressure circulation
Gearbox housing model: 15
Synchronization type: Mechanical shift synchronization
Axle and tire model: WZL100
Gear shift position: 4 forward, 4 reverse
(front/rear) km/h
F1: 5 km/h; F2: 10 km/h; F3: 18 km/h; F4: 32 km/h
R1: 5 km/h; R2: 10 km/h; R3: 18 km/h; R4: 32 km/h
Tire size: 16.9-28
Hydraulic System
Working pump displacement: 63 ml/r
Working pressure: 20 Mpa
Steering gearbox model: BZZ-500
Digging Equipment (Breaker Hammer)
Drill rod diameter: 68-70 mm
Working pressure: 11-14 MPa
Impact frequency: 500-900
Flow rate: 25-45 l/min
Kinetic energy: 49 kN
Oil Capacity
Hydraulic oil tank: 125 L
Diesel fuel tank: 125 L
If you need a different tractor, any power or machine is available — just ask, and you’ll get a prompt response.
Every purchase with us is covered by a warranty for the proper execution of the contract for the amount of PLN 2,000,000 (two million) and an additional PLN 1,000,000 (one million) to secure every one of our subcontractors in the supply chain.
